MTP-II Thermal Printer Specifications

• Model: MTP-II
• Dimensions: 79 mm x 110 mm x 45 mm
• Weight: 235 g (excluding paper roll)
• Print Method: Line thermal printing
• Paper Specifications:
  • Width: 57 mm
  • Max Roll Diameter: 40 mm
• Print Width: 48 mm
• Dot Per Line: 384 dots/line
• Resolution: 203 DPI (8 dots/mm)
• Print Speed: 50 - 80 mm/s
• Life Cycle:
  • 50 km (printing density under 12.5%)
  • 100 million pulses
• Character Support:
  • Internal: ASCII (8x16, 9x17, 9x24, 12x24), GB18030 (16x16, 24x24)
  • Supports: English, symbols, Chinese characters, figures, graphs, curves, pre-stored icons, and barcodes (CODE39, EAN13, EAN8, CODABAR, CODE128, CODE93, ITF).
  • QR Code and PDF417 supported.

Connectivity & Power

• Interfaces: Bluetooth, Mini USB
• Power: 1500 mAh, 7.4V rechargeable lithium battery
• Recharge Adapter: AC adapter for standby recharging

Operational Settings

• Self-Check Features: Detects without paper or if cover is open
• Black Mark Test: Supported
• Paper Feeding: Easy loading design
• Commands: ESC/POS compatible with order sets
• Paper Cutting: Manual
• Operating Temperature: -10°C to 50°C
• Operating Humidity: 20% to 85%
• Recharge Conditions: 5°C to 40°C, 20% to 85% humidity
• Storage Conditions: -20°C to 70°C, 5% to 95% humidity

Accessories

• Standard Accessories:
  • Long-term preservable paper
  • AC adapter
  • Li-ion battery
  • USB cable
• Optional Accessories:
  • Serial interface cable
  • Leather coat
  • CD
